movesx (Auto Mode)

This is a function for moving the robot along a spline curve path that connects the current position to the target position (the last waypoint) via the waypoints of the task space. The input velocity/acceleration means the maximum velocity/acceleration in the path, and the constant-speed motion is performed with the input velocity according to the condition if the option for constant speed motion is selected.

movesx

Definition
DRFLEx.h within class CDRFLEx, public section (line 800)

bool movesx(float fTargetPos[MAX_SPLINE_POINT][NUM_TASK],
            unsigned char nPosCount,
            float fTargetVel[2],
            float fTargetAcc[2],
            float fTargetTime = 0.f,
            MOVE_MODE eMoveMode = MOVE_MODE_ABSOLUTE,
            MOVE_REFERENCE eMoveReference = MOVE_REFERENCE_BASE,
            SPLINE_VELOCITY_OPTION eVelOpt = SPLINE_VELOCITY_OPTION_DEFAULT)
{
    return _movesx(_rbtCtrl, fTargetPos, nPosCount, fTargetVel, fTargetAcc,
                   fTargetTime, eMoveMode, eMoveReference, eVelOpt);
};

Parameter

Parameter Name

Data Type

Default Value

Description

fTargetPos

float [MAX_SPLINE_POINT][6]

Maximum 100 waypoint information

nPosCount

unsigned char

Number of valid waypoint

fTargetVel

float[2]

Linear Velocity, Angular Velocity

fTargetAcc

float[2]

Linear Acceleration, Angular Acceleration

fTargetTime

float

0.f

Reach Time [sec]

eMoveMode

MOVE_MODE

MOVE_MODE_ABSOLUTE

Refer to the Definition of Enumeration Type

eMoveReference

MOVE_REFERENCE

MOVE_REFERENCE_BASE

Refer to the Definition of Enumeration Type

eVelOpt

SPLINE_VELOCITY_OPTION

SPLINE_VELOCITY_OPTION_DEFAULT

Refer to the Definition of Enumeration Type

Note

  • If an argument is inputted to fTargetVel (e.g., fTargetVel ={30, 0}), the input corresponds to the linear velocity of the motion, while the angular velocity is determined proportionally to the linear velocity.

  • If an argument is inputted to fTargetAcc (e.g., fTargetAcc ={60, 0}), the input corresponds to the linear acceleration of the motion, while the angular acceleration is determined proportionally to the linear acceleration.

  • If fTargetTime is specified, values are processed based on fTargetTime, ignoring fTargetVel and fTargetAcc.

  • When eMoveMode is MOVE_MODE_RELATIVE, each pos of the position list is defined as a relative coordinate for the preceding pos. (If position list=[q1, q2, …,q(n-1), q(n)], q1 is the relative angle of the starting point, while q(n) is the relative coordinate of q(n-1).)

  • This function does not support online blending of previous and subsequent motions.

Caution

The constant-velocity motion according to the distance and velocity between the input waypoints cannot be used if the SPLINE_VELOCITY_OPTION_CONST option (constant-velocity option) is selected for eVelOpt, and the motion is automatically switched to the variable-velocity motion (eVelOpt = SPLINE_VELOCITY_OPTION_DEFAULT) in that case.

Return

Value

Description

0

Error

1

Success

Example

// CASE 1 : Moves absolute coordinate standard (mode = MOVE_MODE_ABSOLUTE)
float xpos[4][6];
int   xposNum = 4;
float tvel[2] = { 50, 100 };
float tacc[2] = { 50, 100 };

xpos[0][0]=559; xpos[0][1]=434.5; xpos[0][2]=651.5;
xpos[0][3]=0;   xpos[0][4]=180;  xpos[0][5]=0;

xpos[1][0]=559; xpos[1][1]=434.5; xpos[1][2]=251.5;
xpos[1][3]=0;   xpos[1][4]=180;  xpos[1][5]=0;

xpos[2][0]=559; xpos[2][1]=234.5; xpos[2][2]=251.5;
xpos[2][3]=0;   xpos[2][4]=180;  xpos[2][5]=0;

xpos[3][0]=559; xpos[3][1]=234.5; xpos[3][2]=451.5;
xpos[3][3]=0;   xpos[3][4]=180;  xpos[3][5]=0;

drfl.movesx(xpos, xposNum, tvel, tacc, 0, MOVE_MODE_ABSOLUTE);
// Moves the spline curve that connects the waypoints defined in xpos
// with a maximum linear/angular velocity of 50 and maximum acceleration of 100.

// CASE 2 : Moves relative coordinate standard (mode = MOVE_MODE_RELATIVE)
float xpos2[4][6];
xpos2[0][0]=0;   xpos2[0][1]=+400; xpos2[0][2]=0;
xpos2[0][3]=0;   xpos2[0][4]=0;    xpos2[0][5]=0;   // from start position -> x0

xpos2[1][0]=0;   xpos2[1][1]=0;   xpos2[1][2]=+400;
xpos2[1][3]=0;   xpos2[1][4]=0;   xpos2[1][5]=0;   // from x0 -> x1

xpos2[2][0]=0;   xpos2[2][1]=+200; xpos2[2][2]=0;
xpos2[2][3]=0;   xpos2[2][4]=0;    xpos2[2][5]=0;   // from x1 -> x2

xpos2[3][0]=0;   xpos2[3][1]=0;    xpos2[3][2]=+200;
xpos2[3][3]=0;   xpos2[3][4]=0;    xpos2[3][5]=0;   // from x2 -> x3

drfl.movesx(xpos2, xposNum, tvel, tacc, 0, MOVE_MODE_RELATIVE);
// Moves the spline curve that connects the relative waypoints in xpos2
// with max velocity 50 (mm/sec, deg/sec) and max acceleration 100 (mm/sec2, deg/sec2).
