Architecture

This architecture illustrates the data flow between user commands, controller layers, and DRCF (Doosan Robot Control Framework).



Doosan ROS 2 Architecture



The Doosan ROS 2 control stack follows the standard ros2_control architecture. It provides a modular interface between user-level applications (e.g., MoveIt 2), control logic, and physical Doosan robot hardware.



Controller Manager (CM)

The Controller Manager is responsible for managing and executing control loops. It loads and activates controllers such as JointTrajectoryController for arm motion. In the Doosan setup, the controller manager interacts with the dsr_hardware2 plugin, which represents the robot hardware.

The CM’s update() loop follows this cycle:

  1. read() – Read sensor data from the robot via dsr_hardware2.

  2. controller update – Execute the control logic (e.g., trajectory tracking).

  3. write() – Send joint commands back to the robot through dsr_hardware2.

The CM also exposes ROS 2 services for controller lifecycle operations.



Controllers

In the Doosan ROS 2 control system, controllers are modular plugins that perform feedback-based motion control. Each controller compares the desired trajectory (reference) with the current joint state and computes the necessary control commands.

Controllers are implemented as classes derived from ControllerInterface and are loaded using the pluginlib library.

Common examples include:

  • JointTrajectoryController: Handles arm motion through trajectory interpolation.

  • GripperCommandController: Sends simple open/close commands to a gripper.

  • ForwardCommandController: Sends direct position or velocity commands.

The Doosan control package (dsr_bringup2) includes the following custom controllers:

  • dsr_controller2: Provides direct command-level access to the DRFL API (movej, movel, etc.).

  • dsr_joint_trajectory: Executes buffered joint trajectories using the Doosan native motion engine.

  • dsr_moveit_controller: Standard JointTrajectoryController compatible with MoveIt 2.

  • dsr_position_controller: A ForwardCommandController for position control of each joint.

Controllers operate on a lifecycle model (LifecycleNode) and transition through states such as unconfigured, inactive, and active.

During the control loop, the update() method is called to:

  • Read the latest joint states (via the state_interface)

  • Compute control commands

  • Write to the command_interface (e.g., position, velocity)



User Interfaces

Users interact with the control system primarily via Controller Manager services. These services allow dynamic loading, activation, deactivation, and switching of controllers at runtime.

Example usage with CLI:

ros2 control list_controllers
ros2 control load_controller joint_trajectory_controller
ros2 control set_controller_state --activate joint_trajectory_controller

You can also interface with the controller manager using:

  • RViz2 GUI (via MoveIt 2)

  • Custom ROS 2 nodes

  • Python or C++ service clients

For a complete list of available services, refer to controller_manager_msgs/srv/.



Hardware Components

In the Doosan system, the robot is abstracted as a single System hardware component using the dsr_hardware2 plugin.

This system interface provides:

  • State Interfaces: Current joint positions and velocities

  • Command Interfaces: Target joint positions and velocities

Key features:

  • Communicates with the physical robot via the DRFL API

  • Supports both real and virtual robot modes

  • Implements the required read() and write() methods for hardware synchronization
